Safety Precautions

Always follow safety guidelines to avoid electrical shock‚ explosion‚ or fire․ Read the manual carefully before use․ Ensure correct polarity connections and proper disconnection order to prevent hazards․

Never ignore safety warnings to prevent serious injury or property damage․
Connect clamps correctly to avoid reverse polarity‚ which can cause damage or fire․
Disconnect in reverse order to ensure safety and prevent electrical surges․

Failure to follow instructions may result in severe consequences․

1․1 General Safety Guidelines

Read and understand all safety information before using the NOCO Boost HD․ Failure to follow guidelines may result in electrical shock‚ explosion‚ fire‚ or serious injury․ Always ensure proper connections and avoid reverse polarity․ Disconnect devices in the correct order to prevent hazards․ Keep the device away from flammable materials and ensure it is used in well-ventilated areas․ Avoid overcharging or improper storage‚ as this can lead to damage or safety risks․ Follow all warnings and precautions to ensure safe operation and prevent potential harm to yourself or property․ Proper usage and adherence to guidelines are crucial for optimal performance and safety․

1․2 Handling the Battery and Clamps

Handle the NOCO Boost HD battery and clamps with care to avoid damage or injury․ Always wear protective gloves and eyewear when connecting or disconnecting the clamps․ Ensure the clamps are securely attached to the correct polarity terminals (positive to positive‚ negative to negative or chassis)․ Avoid touching metal parts to prevent short circuits․ Never connect clamps to non-battery terminals‚ such as fuel lines or electrical components․ If the battery is below 2 volts‚ use the Manual Override feature with caution․ Keep the clamps away from children and ensure they are stored properly when not in use․ Proper handling ensures safety and extends the lifespan of the device․

1․3 Proper Storage Conditions

Store the NOCO Boost HD in a cool‚ dry‚ well-ventilated area away from flammable materials and moisture․ Avoid extreme temperatures‚ ideally between -20°C and 50°C (-4°F to 122°F)․ Keep the device away from direct sunlight and heat sources․ For long-term storage‚ charge the battery to 50% to prevent deep discharge․ Clean the clamps and device before storing to prevent corrosion․ Use the original storage case to protect the unit from physical damage․ Ensure the storage area is out of reach of children․ Proper storage maintains the battery’s health‚ ensures safety‚ and extends the lifespan of the device․

Getting Started

Unpack and inspect the device for damage․ Understand the features and controls before first use․ Charge the unit fully to ensure optimal performance and longevity․

2․1 Unpacking and Initial Inspection

Begin by carefully unpacking the NOCO Boost HD GB70 from its box․ Inspect the device and all accessories for any visible damage or defects․ Check the HD battery clamps‚ USB cables‚ and the unit itself for signs of wear or damage․ Ensure all components are included as listed in the manual․ If any damage is found‚ contact NOCO support immediately․ This step ensures the device is in proper working condition before first use‚ preventing potential safety hazards or functional issues․ Proper inspection helps guarantee safe and effective operation of the jump starter․

2․2 Understanding the Device Features

The NOCO Boost HD GB70 is an ultra-compact lithium-ion jump starter designed for high-displacement gas and diesel engines․ It features a peak current of 2000A‚ making it suitable for cars‚ trucks‚ boats‚ and more․ The device includes HD battery clamps for secure connections‚ a USB port for charging smartphones and other devices‚ and an LED indicator for charge status; The error LED alerts users to issues like reverse polarity or high temperatures․ The GB70 also supports multiple languages and comes with a comprehensive user guide․ Understanding these features ensures safe and effective use of the jump starter for various vehicles and charging needs․

2․3 First-Time Charging Requirements

Before first use‚ charge the NOCO Boost HD GB70 using the provided micro USB cable and a USB adapter․ Connect the micro USB to the device and plug the adapter into a wall outlet․ The charging process typically takes 2-3 hours․ Ensure the device is charged in a cool‚ dry environment to optimize battery performance․ The LED indicators will show the charging progress‚ with the red LED turning solid when fully charged․ Avoid overcharging to maintain battery health․ Always use the original or recommended charging accessories to prevent damage․ Proper charging ensures the device is ready for jump-starting or powering USB devices effectively․

Jump Starting a Vehicle

Connect HD clamps to correct battery terminals: positive to positive‚ negative to negative or chassis․ Turn on the device‚ start the vehicle․ If it doesn’t start immediately‚ wait 20-30 seconds and try again․ Do not attempt more than five consecutive jumps in 15 minutes․ Allow the GB70 to rest for 15 minutes between attempts․

3․1 Preparing for Jump Starting

Before jump starting‚ ensure the vehicle is turned off and in park or neutral․ Verify the battery voltage and chemistry․ The GB70 supports 12V lead-acid batteries down to 2V․ If the battery is below 2V‚ use the Manual Override feature by pressing the red button for 3 seconds․ Ensure the GB70 is fully charged for optimal performance․ Check for any damage to the HD clamps or cables․ Always wear protective eyewear and keep flammable materials away․ Ensure proper ventilation to avoid hydrogen gas buildup․ Follow all safety precautions to prevent electrical shock or explosion․ Never connect clamps to non-battery sources or metal components․ Proceed with caution and follow the device instructions carefully․

3․2 Connecting the HD Battery Clamps

Connect the positive (red) HD clamp to the positive (POS‚ P‚ +) battery terminal․ Next‚ attach the negative (black) clamp to the negative (NEG‚ N‚ -) terminal or a metal chassis ground․ Ensure clamps are secure and not touching any moving parts․ For vehicles with high-displacement engines‚ the GB70 may need to be connected for up to 30 seconds before starting․ Do not connect clamps to non-battery sources or metal components․ If the battery is below 2V‚ use the Manual Override feature․ Always check for proper connections and avoid short circuits․ Proceed with caution and ensure no flammable materials are nearby․

3․3 Starting the Vehicle

After securely connecting the HD clamps‚ ensure all vehicle electronics are off․ Press the Boost button to activate․ Most vehicles start immediately‚ but some may require up to 30 seconds․ If the vehicle doesn’t start‚ wait 20-30 seconds before retrying․ Do not attempt more than five jump starts in 15 minutes․ Allow the GB70 to rest for 15 minutes between attempts․ Once the engine starts‚ remove the clamps in reverse order: negative first‚ then positive․ Avoid touching metal components with the clamps to prevent sparks․ If the battery is below 2V‚ use Manual Override for a forced start․ Always follow safety guidelines to prevent electrical hazards․

3․4 Post-Jump Start Procedures

After successfully starting the vehicle‚ remove the HD clamps in reverse order: disconnect the negative (black) clamp first‚ followed by the positive (red) clamp․ Ensure no metal parts touch during disconnection to avoid sparks․ Check the GB70 for any error indicators‚ such as a blinking red LED‚ which may signal overheating․ Allow the device to cool if necessary․ Recharge the GB70 if its battery level is low to maintain performance․ Store the device properly‚ ensuring clamps are secure and not touching metal objects․ Always follow safety guidelines to prevent electrical hazards and ensure proper functionality for future use․ Regular maintenance and storage will extend the lifespan of your NOCO Boost HD․

Charging the NOCO Boost HD

Charge the NOCO Boost HD using the included USB cable or 12V adapter․ Monitor the LED indicators for charge progress: red indicates charging‚ green for full charge․ Optimal charging time is 3-4 hours for a full battery‚ ensuring peak performance and longevity․

4․1 Recommended Charging Methods

The NOCO Boost HD should be charged using the provided Micro USB cable or a compatible 12V adapter․ Connect the Micro USB cable to the USB IN port and plug the other end into a 5V‚ 2․1A power source․ For faster charging‚ use the 12V input port with a 12V‚ 3A adapter․ The LED indicators will show the charging progress: red for charging and green when fully charged․ Ensure the device is stored in a cool‚ dry place during charging to optimize battery health․ Avoid overcharging to maintain longevity․ Always use NOCO-approved chargers to prevent damage and ensure safety․

4․2 Understanding Charge Indicators

The NOCO Boost HD features LED indicators to monitor charging status․ The 25%‚ 50%‚ 75%‚ and 100% charge levels are indicated by progressive LED lights․ When charging‚ the red LED pulses until the battery reaches 25%‚ then turns solid․ As charging progresses‚ subsequent LEDs illuminate to show 50%‚ 75%‚ and finally 100% charge․ The green LED signifies the device is fully charged and ready for use․ These indicators provide clear visual feedback‚ ensuring you know the battery’s status at a glance․ Always monitor the LEDs during charging to avoid overcharging and maintain optimal battery performance․ This system is designed for user convenience and battery longevity․

4․3 Optimal Charging Times

The NOCO Boost HD typically requires 3-4 hours for a full charge․ Charging times vary based on the battery’s initial charge level and the charger used․ The LED indicators provide real-time feedback: the red LED pulses during charging‚ turning solid at 25%‚ with subsequent LEDs illuminating at 50%‚ 75%‚ and 100%․ For optimal performance‚ avoid overcharging‚ as this can degrade battery life․ Monitor the LEDs to ensure the device is charged correctly․ Using the original charger is recommended for safety and efficiency․ Allow the battery to cool before storing or using it again․ Proper charging practices help maintain the device’s longevity and performance․

Using the Manual Override Feature

5․1 When to Use Manual Override

Use Manual Override for batteries below 2V․ Press and hold the red exclamation button for 3 seconds to activate․ Ensure clamps are connected correctly․

Activate only when the Boost LED is off due to low voltage․

The Manual Override feature is used when the battery voltage is below 2V‚ and the Boost LED is off․ Press and hold the red exclamation button for 3 seconds to activate it․ Ensure the HD clamps are connected to the correct polarity terminals before activating․ This feature bypasses automatic safety protocols‚ so use it cautiously․ Only activate Manual Override if the battery is severely discharged but still salvageable․ Improper use can damage the device or cause safety hazards․ Always follow safety guidelines and disconnect properly after use to avoid electrical risks․

Activate only when the Boost LED is off due to low voltage․
Ensure clamps are securely connected to correct terminals․

<br />

Avoid using Manual Override unless necessary․

5․2 Activating the Manual Override

To activate the Manual Override‚ press and hold the red exclamation mark button for three seconds․ The White Boost LED will flash‚ indicating activation․ Ensure the HD clamps are connected to the correct battery terminals before starting․ Once activated‚ attempt to start the vehicle․ If unsuccessful‚ wait 20-30 seconds before retrying․ Do not attempt more than five consecutive jump starts within 15 minutes․ Allow the device to cool down for 15 minutes if it overheats․ Always follow safety guidelines to prevent electrical hazards․

Press and hold the red button for three seconds․
Ensure clamps are connected correctly before activation․
Limit consecutive jump starts to avoid overheating․

5․3 Safety Considerations for Manual Override

Using Manual Override requires caution to prevent hazards․ Always connect HD clamps to correct polarity terminals․ Avoid sparks by ensuring clamps do not touch metal objects․ If the battery is below 2V‚ use override sparingly․ Do not use near open flames or explosive environments․ Disconnect all loads before activation․ The device may overheat with excessive use; allow cooling periods․ Follow all safety guidelines to prevent injury or damage․

Ensure correct polarity connections to avoid sparks․
Prevent metal contact to avoid accidental short circuits․
Avoid use in flammable environments for safety․

Charging USB Devices

Charge USB devices like smartphones using the USB OUT port․ Connect the cable to your device for convenient power on the go․

Compatible with most USB devices․
Charging times vary by device․

6․1 Compatible USB Devices

The NOCO Boost HD supports charging for a wide range of USB devices‚ including smartphones‚ tablets‚ and other portable electronics․ The USB OUT port provides a standard 5V‚ 2;1A output‚ ensuring compatibility with most modern devices․ Simply connect your device using the included USB cable or any compatible cable․ The GB70 is designed to safely charge devices‚ and its port is protected against overcurrent and short circuits․ This feature makes it ideal for keeping your devices powered on the go‚ whether you’re charging a smartphone or other USB-powered accessories․ Always ensure your device is compatible with the USB output specifications for optimal charging performance․

6․2 Charging Times for USB Devices

Charging times for USB devices using the NOCO Boost HD vary depending on the device’s battery capacity and the USB port’s output․ The GB70 provides a 5V‚ 2․1A USB output‚ which is suitable for most smartphones‚ tablets‚ and other portable electronics․ For example‚ a smartphone with a 3‚000mAh battery can be fully charged in approximately 1․5 to 2 hours․ Smaller devices like smartwatches or earbuds may charge in 30 minutes or less․ Actual charging times may vary based on the device’s specifications and its current battery level․ Always use the included USB cable or a compatible one for optimal charging performance․

Error Handling and Troubleshooting

The error LED indicates issues like reverse polarity or high battery temperature․ If blinking red‚ allow the unit to cool or check connections․ Ensure proper usage to resolve errors effectively․

7․1 Understanding Error Indicators

The NOCO Boost HD features an error LED that illuminates red to signal issues․ If the LED blinks‚ it indicates high internal battery temperature or reverse polarity connections․ When the Boost LED is off‚ it may signify a battery voltage below 2V‚ requiring manual override․ Understanding these indicators helps diagnose and resolve problems efficiently․ Always refer to the user guide for detailed explanations and solutions to ensure safe and effective troubleshooting․ Properly addressing error indicators is crucial for maintaining device functionality and user safety․

7․2 Common Issues and Solutions

The NOCO Boost HD may encounter issues like low battery detection or high temperature warnings․ If the error LED blinks red‚ allow the device to cool down․ For batteries below 2V‚ use the manual override feature to force-start the vehicle․ Ensure all connections are secure and correct to avoid reverse polarity errors․ If the Boost LED doesn’t illuminate‚ check the battery voltage and connections․ Refer to the troubleshooting guide for step-by-step solutions․ Regular maintenance and proper storage can prevent many common issues‚ ensuring optimal performance and longevity of the device․ Always follow safety guidelines when addressing these problems to avoid further complications․

Technical Specifications

The NOCO Boost HD GB70 features a 12V lithium-ion battery with 2000A peak current‚ operating temperatures from -30°C to 50°C‚ and USB ports for device charging․

Battery Type: Lithium-ion
Peak Current: 2000A
Operating Temperature: -30°C to 50°C
USB Output: 5V‚ 2․1A

8․1 Battery Type and Capacity

The NOCO Boost HD GB70 is equipped with a high-performance lithium-ion battery‚ designed for reliable jump-starting and long-lasting energy storage․ Its advanced lithium-ion technology ensures safety‚ portability‚ and durability‚ making it suitable for various vehicles․ The battery’s capacity supports multiple jump starts on a single charge‚ while its compact design allows easy storage and transport․ With a focus on efficiency‚ the lithium-ion battery provides consistent power delivery‚ even in extreme temperatures‚ ensuring optimal performance for high-displacement gas and diesel engines․ This technology also enables rapid charging and maintains battery health over time‚ making it a dependable solution for emergency situations․

8․2 Peak Current and Operating Temperatures

The NOCO Boost HD GB70 delivers a peak current of 2000A‚ enabling it to jump-start high-displacement gas and diesel engines effortlessly․ Designed for versatility‚ it operates in temperatures ranging from -30°C to 50°C (-22°F to 122°F)‚ ensuring reliability in extreme environments․ The charging process is optimized for temperatures between 0°C and 40°C (32°F to 104°F)‚ while storage is recommended in temperatures from -20°C to 50°C (-4°F to 122°F)․ These specifications ensure consistent performance and longevity‚ making the device suitable for use in diverse climatic conditions․ The robust design and thermal management system safeguard the unit against overheating and cold-related issues‚ ensuring safe and efficient operation․

8․3 Input/Output Ports and Ratings

The NOCO Boost HD GB70 features a Micro USB input port rated at 5V‚ 2;1A for charging the internal battery․ The USB output port provides 5V‚ 2․1A for charging external devices like smartphones․ The 12V input port supports 12V‚ 3A for charging via a vehicle or wall adapter‚ while the 12V output port delivers 12V‚ 15A for powering accessories․ The HD battery clamps have a peak current rating of 2000A‚ ensuring reliable jump-starting for high-displacement engines․ These ports and ratings ensure versatile and efficient energy delivery‚ catering to both charging and powering needs․ Proper usage of these ports is essential for maintaining device performance and safety․

Maintenance and Care

Regular maintenance ensures optimal performance․ Clean the device with a soft cloth and avoid harsh chemicals․ Store in a cool‚ dry place to prevent damage․ Update firmware as needed for improved functionality and safety․ Proper care extends the lifespan and reliability of the NOCO Boost HD․

Clean the HD clamps regularly to maintain good electrical contact․
Check for firmware updates to ensure you have the latest features․
Store the device in a protective case when not in use․

9․1 Cleaning the Device

Regular cleaning ensures optimal performance and longevity․ Use a soft‚ dry cloth to wipe the exterior‚ avoiding harsh chemicals or abrasive materials․ Disconnect the device before cleaning to prevent accidental start-ups․ For the HD clamps‚ gently remove dirt or corrosion with a clean cloth․ Avoid submerging the device in water or exposing it to excessive moisture․ Inspect the clamps and ports for debris and clean them periodically to maintain proper electrical contact․ Store the device in a protective case when not in use to prevent scratches or damage․ Proper cleaning and maintenance ensure reliable operation and extend the lifespan of your NOCO Boost HD․

9․2 Updating Firmware (If Applicable)

Regular firmware updates ensure optimal performance and security․ Check the manufacturer’s website for the latest updates․ Before updating‚ fully charge the device to prevent interruptions․ Download the update file from the official NOCO website and follow the instructions provided․ Connect the device to your computer using the provided USB cable․ Do not disconnect the device during the update process‚ as this may cause malfunctions․ Once the update is complete‚ restart the device to apply the changes․ If issues arise‚ consult the user manual or contact NOCO support for assistance․ Keeping the firmware updated ensures compatibility and enhances functionality․

9․3 Long-Term Storage Tips

Store the NOCO Boost HD in a cool‚ dry place away from direct sunlight and moisture․ Avoid extreme temperatures‚ as this can degrade the battery․ Charge the device to at least 50% capacity before storing to prevent deep discharge․ Do not fully drain the battery‚ as this can reduce its lifespan․ Place the device in a protective case to avoid physical damage․ Recharge every 6 months to maintain optimal battery health․ Ensure the storage area is well-ventilated to prevent the buildup of flammable gases․ By following these tips‚ you can extend the life of your NOCO Boost HD and ensure it remains reliable when needed․

Warranty and Support

Contact NOCO support at 1-800-456-6626 or support@no․co for assistance․ The warranty covers defects in materials and workmanship․ Visit www․no․co/support for detailed terms and conditions․

Phone: 1․800․456․6626
Email: support@no․co
Mailing Address: 30339 Diamond Parkway‚ 102 Glenwillow‚ OH 44139

10․1 Warranty Terms and Conditions

The NOCO Boost HD GB70 is covered by a limited warranty that protects against defects in materials and workmanship for a specified period․ The warranty is non-transferable and applies to the original purchaser only․ For full terms‚ refer to the product manual or contact NOCO support․ The warranty does not cover damage caused by misuse‚ neglect‚ or unauthorized modifications․ Contact NOCO at 1-800-456-6626 or visit www․no․co/support for warranty claims or inquiries․ Mailing Address: 30339 Diamond Parkway‚ 102 Glenwillow‚ OH 44139․

10․2 Contacting NOCO Support

For assistance‚ contact NOCO support at 1-800-456-6626 or via email at support@no․co․ Visit www․no․co/support for comprehensive resources and troubleshooting guides․ Mailing Address: 30339 Diamond Parkway‚ 102 Glenwillow‚ OH 44139․ Ensure to have your product details ready for efficient service․ NOCO support is available to address inquiries‚ provide technical assistance‚ and process warranty claims․ For product-related questions or issues‚ utilize the support options to receive timely and professional help․

Legal Information

11․1 Disclaimer of Liability

NOCO disclaims liability for damages resulting from misuse or improper handling of the NOCO Boost HD․ Users must follow instructions to avoid risks․ NOCO is not responsible for third-party claims or consequential damages․ All products are provided “as is” without warranties of any kind․ By using NOCO products‚ users agree to these terms․ NOCO reserves the right to modify or update this disclaimer without notice․ Always refer to the latest legal information provided by NOCO․ Failure to comply with these terms may result in legal action․ NOCO’s liability is limited to the extent permitted by law․

11․2 Intellectual Property Rights

All content‚ designs‚ and technologies in the NOCO Boost HD are protected under U․S․ and international intellectual property laws․ NOCO retains all rights to its trademarks‚ patents‚ and copyrights․ Unauthorized use‚ reproduction‚ or distribution of NOCO’s intellectual property is prohibited․ The NOCO Boost HD and its documentation are for personal use only․ Any commercial use requires prior written consent from NOCO․ Infringement of these rights may result in legal action․ NOCO actively enforces its intellectual property rights to protect its innovations․ Users must respect these rights to avoid legal consequences․ NOCO’s intellectual property rights are non-transferable and remain solely with NOCO․
